keepass openwrt sftp 구성
keepass.kdbx를 openwrt openssh-sftp-server에 올려 home-lab 패스워드 관리자 구성
Categories:
graph LR subgraph agq3mbw2 A[openwrt] --- B1[keepass.kdbx] A[openwrt] --- B2[ssh] end B2 ---- D[duckdns] D <-- ssh --> C1[clients] C1 --- C2[keepass.keyx]
openwrt 구성
포트 개방
vi /etc/config/firewall
...
config redirect
option dest 'lan'
option target 'DNAT'
option name 'agq3mbw2-ssh'
option src 'wan'
option dest_port '22'
list proto 'tcp'
option dest_ip '192.168.192.1'
option family 'ipv4'
option src_dport '5****'
...
/etc/init.d/firewall restart
계정 추가
echo "dev:x:1000:1000:dev:/home/dev:/bin/ash" >> /etc/passwd && \
echo "dev:x:1000:dev" >> /etc/group && \
echo "dev:19073:0:99999:7:::" >> /etc/shadow && \
passwd dev
_***************************************************************
mkdir -p /home/dev/.ssh && \
echo "ssh-ed25519 A******************************************************************* agq3mbw2-eddsa-key-20230927
" | sudo tee /home/dev/.ssh/authorized_keys && \
chmod 755 /home && \
chmod 755 /home/dev && \
chmod 700 /home/dev/.ssh && \
chmod 600 /home/dev/.ssh/authorized_keys && \
chown -R dev:dev /home/dev
echo "vscp5ekq:x:1001:1000:vscp5ekq:/home/vscp5ekq:/bin/ash" >> /etc/passwd && \
echo "agq3mbw2:x:1000:vscp5ekq" >> /etc/group && \
echo "vscp5ekq:.:0:0:99999:7:::" >> /etc/shadow && \
passwd vscp5ekq
Z***************************************************************
mkdir -p /home/vscp5ekq/.ssh && \
echo "ssh-rsa A*****************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************************== generated by Keepass2Android
" | sudo tee /home/vscp5ekq/.ssh/authorized_keys && \
chmod 755 /home && \
chmod 755 /home/vscp5ekq && \
chmod 700 /home/vscp5ekq/.ssh && \
chmod 600 /home/vscp5ekq/.ssh/authorized_keys && \
chown -R vscp5ekq:dev /home/vscp5ekq
dropbear
cat << EOF | tee /etc/config/dropbear
config dropbear
option Port '22'
option PasswordAuth 'off'
option RootPasswordAuth 'off'
option GatewayPorts 'on'
EOF
/etc/init.d/dropbear restart
패키지 설치
opkg update && \
opkg install luci-app-ddns drill curl openssh-sftp-server
ddns
vi /etc/config/ddns
config ddns 'global'
option ddns_dateformat '%F %R'
option ddns_loglines '250'
option ddns_rundir '/var/run/ddns'
option ddns_logdir '/var/log/ddns'
option use_curl '1'
config service 'duckdns'
option service_name 'duckdns.org'
option use_ipv6 '0'
option enabled '1'
option password 'b*******-****-****-****-************'
option use_https '1'
option ip_source 'network'
option ip_network 'wan'
option interface 'wan'
option use_syslog '2'
option check_unit 'minutes'
option force_unit 'minutes'
option retry_unit 'seconds'
option param_enc 'https://www.duckdns.org/update?domains=agq3mbw2&token=b*******-****-****-****-************'
option cacert '/etc/ssl/certs/ca-certificates.crt'
option lookup_host 'sj9n7air.duckdns.org'
option domain 'sj9n7air.duckdns.org'
option username 'sj9n7air'
/etc/init.d/ddns restart
db 권한
chown dev:dev -R /usr/share/keepass && \
chmod 770 /usr/share/keepass && \
chmod 660 /usr/share/keepass/fhy8vp3u.kdbx
windows 구성
KeePass.config.xml
vi $APPDATA/KeePass/KeePass.config.xml
...
<DatabasePath>sftp://sj9n7air.duckdns.org:5****/usr/share/keepass/fhy8vp3u.kdbx</DatabasePath>
<KeyFilePath>..\..\Users\dev\AppData\Roaming\KeePass\fhy8vp3u.keyx</KeyFilePath>
...
License
상업적 이용 제한 없음
Troubleshooting
android 버전은 ssh키를 앱에서 관리하고 외부키를 사용할 수 없음 3
각 클라이언트별 계정 생성 외에는 방법이 없다
